GitHub - Usage

To use the GitHub plug-in, the plug-in must be loaded and an instance created before you can configure the plug-in integration. Configuration properties are defined using the product user interface or a JSON file.

Integration type

The GitHub plug-in supports scheduled events integration which are listed in the following table.

Name Description
syncGithubIssuesEvent Queries the GitHub repository for issues.
syncGithubCommitsEvent Queries the GitHub repository for commits.
syncGithubPullRequestsEvent Queries the GitHub repository for pull requests.
Sync GitHub Actions Query for CI processes using GitHub Actions in a repository
Sync GitHub Yaml File Query GitHub for yaml file in repository

Integration

To install the plug-in, perform the following steps:

  1. In IBM DevOps Velocity, click Settings > Integrations > Available.
  2. In the Action column for the GitHub plug-in, click Install.

There are two methods to integrate the plug-in:

  1. Using the user interface
  2. Using a JSON file

The tables in the Configuration properties describe the properties used to define the integration.

Integrating the plug-in by using user interface

To integrate the plug-in using the user interface, perform the following steps:

  1. In IBM DevOps Velocity, click Settings > Integrations > Installed.
  2. In the Action column for the GitHub plug-in, click Add Integration.
  3. On the Add Integration dialog, enter the values for the fields to configure the integration and define communication.
  4. Click Add.

Integrating the plug-in by using JSON file

The JSON file contains the information for creating a value stream. Within the JSON file is a section for integrations. It is in this section that plugin properties can be defined. Refer to the JSON sample code in the Configuration Properties section.

To integrate the plug-in using a JSON, perform the following steps:

  1. Navigate to value stream page, and then click the necessary value stream.
  2. Click wrench icon, and then Select Edit value stream, to modify the JSON file in the code or tree view editors. Alternatively, you can also click Download JSON option to download the JSON file, and then select the Import JSON option to upload the revised JSON file.
  3. Edit the integration information in the JSON file to add the plug-in configuration properties. Refer to JSON sample code in the Configuration Properties section more details.
  4. Click Save.

Minimum permission to integrate with GitHub

The access token generated from GitHub server requires the Full control of private repositories permission to connect to the Github.

Wildcard Functionality added in this Plugin:

Wildcard functionality: A new way to specify multiple repositories in the GitHub plugin without having to manually modify the integration each time. Regular expressions would be most valuable and dynamic. Example: ucv-ext-, repo-name, repo-abc. to specify multiple repositories which containe the same pattern in their name.

Previously: Must list every plugin manually to be imported. Example: ucv-ext-jira, ucv-ext-appscan, ucv-ext-sonarqube With this functionality : Single regex will import all repositories. Example: ucv-ext-*.

Configuration properties

The following tables describe the properties used to configure the integration. Each table contains the field name when using the user interface and the property name when using a JSON file.

General Configuration Properties table

Name Description Required Property Name
NA The version of the plug-in that you want to use. To view available versions, click the Version History tab. If a value is not specified, the latest version is used. No image
Integration Name An assigned name to the value stream. Yes name
Logging Level The level of Log4j messages to display in the log file. Valid values are: all, debug, info, warn, error, fatal, off, and trace. No loggingLevel
NA List of configuration properties used to connect and communicate with the GitHub server. Enclose the properties within braces. Yes properties
  The name of the tenant. Yes tenant_id
NA Unique identifier assigned to the plug-in. The value for the GitHub plug-in is ucv-ext-github Yes type
IBM DevOps Velocity User Access Key An auto-generated user access key provides credentials for communicating with the IBM DevOps Velocity server. Yes NA

GitHub Configuration Properties table

Name Type Description Required Property Name
API URL String The URL to the REST API v3 for the GitHub instance. Yes apiUrl
DevOps Velocity User Access Key String The user access key generated from IBM DevOps Velocity used to authenticate with the IBM DevOps Velocity server. Yes ucvAccessKey
Owner String The owner name of the GitHub repository. Yes owner
Repositories Array List of GitHub repositories, Use either Repositories field or name field to specify the repositories. Yes repositories
branch String GitHub repositories branch, The branch to pull commits from. No branch
Personal access token String The Personal Access Token used to authenticate with Github repositories. No token
Additional branches Array Additional branches to collect commits from besides the main one, leave blank if not needed. No otherBranches
Proxy Server String The URL of the proxy server including the port number. No proxyServer
Proxy User Name String The user name used to authenticate with the proxy server. No proxyUsername
Proxy Password String The password used to authenticate with the proxy server. No proxyPassword

JSON code example

The following example can be used as a template to define the integration within the JSON file for a value stream. Copy and paste the template into the JSON file and make the appropriate changes.


"integrations":[ {
    "type":"ucv-ext-github",
    "tenant_id":"tenant-id",
    "name":"github-integration-name",
    "properties":{
        "owner":"owner-name",
        "repositories":[
            "repo1",
            "repo2",
            "repo3"
        ],
        "apiUrl":"github-api-url",
        "token":"generated-token",
        "ucvAccessKey":"generated-access-key",
        "proxyServer": "*proxy_server_url*",
        "proxyUsername": "*proxy_server_user_name*",
        "proxyPassword": "*proxy_server_password*"
    }
} ]

Note:

Altering the ‘repositories’ field in the settings will not automatically eliminate any pre-existing data from older integrations. If your goal is to solely display information related to the newly updated repository, it’s necessary to first remove the old integration. After that, you can create a new integration that includes the updated list of repositories.
